Valves are essential in many mechanical systems, regulating the flow of liquids and gases. They control fluids' flow rate, direction, and pressure, making them vital for oil and gas, water treatment, chemical processing, and power generation industries. Valves come in various shapes and sizes to suit different applications and working conditions. This article will discuss different valve varieties and their functions. These include gate valves, globe valves, check valves, ball valves, butterfly valves, and needle valves.

Gate valves

Gate valves are one of the most common ones used in various industries, designed to either fully open or fully close, making them ideal for applications requiring complete on/off control of fluid flow. Gate valves consist of a gate or wedge-shaped disk, which slides up and down between two seat rings to regulate the flow. When fully opened, the gate lies flat against the bottom of the valve, allowing for an unobstructed flow. In contrast, when fully closed, the gate seals tightly against the seats, preventing fluid from passing through.

There are two main types of gate valves - solid wedge and flexible wedge. Solid wedge gates suit liquids and gases with clean flows, while flexible wedges accommodate fluids with suspended solids or slurries. Pipelines, water treatment plants, and oil and gas refineries commonly use gate valves.

Globe valves

Globe valves, also known as stop-check valves, are another popular type of valve used in various industries. They consist of a spherical body with a movable plug-shaped disk that controls the flow. The disk moves up and down against a seat to regulate the fluid's flow rate, making it suitable for applications that require throttling control or partial opening/closing.

One of the main advantages of globe valves is their excellent shut-off capability, which prevents any backflow or leakage when in the closed position. They also have a higher pressure drop than other valves, making them ideal for high-pressure systems. Steam systems and industries such as chemical and petrochemical processing commonly use globe valves.

Check valves

Check valves or non-return or one-way valves, are designed to allow fluid flow in only one direction. They prevent backflow or reverse flow, which can cause damage to equipment and disrupt system operations. Pipelines, pumps, compressors, and other systems commonly use check valves.

There are four main types of check valves - swing check, lift check, ball check, and diaphragm check valves. The swing check valve is the most prevalent type, characterized by a hinged flap that effortlessly swings open to facilitate unidirectional flow while effectively sealing shut to impede any backflow. This ingenious design ensures optimal flow control, preventing any undesired reverse flow. Lift check valves have a disc or cone-shaped disk that lifts off the seat when fluid flows in the desired direction and drops back down to block reverse flow. Ball check valves use a ball as the closing element, while diaphragm check valves utilize a flexible membrane.

Ball valves

Ball valves are another popular variety used in various industries, including oil and gas, chemical processing, and water treatment. A ball valve consists of a round ball with a hole at the center that rotates to control the flow. The ball opens When the handle is parallel to the pipe, allowing full flow. The hole is blocked when turned perpendicular to the pipe, stopping the flow.

One of the main advantages of ball valves is their quick opening and closing action, making them suitable for applications that require frequent on/off control. They also have a low-pressure drop and can handle high temperatures and pressures, making them ideal for critical operations. Pipelines, refineries, and storage tanks commonly use ball valves.

Butterfly valves

Butterfly valves, named after their butterfly-like disk, are another type of quarter-turn valve commonly used in large pipelines and systems. They have a circular body with a rotating disk that controls the flow. When fully open, the disk is parallel to the pipe, allowing full flow. In contrast, when fully closed, the disk is perpendicular, blocking the flow.

Butterfly valves are ideal for handling large volumes of fluid since they have a lower pressure drop than other valves. They also have a compact design and require less space than different valves. However, their use is limited to low-pressure applications due to their construction materials and sealing capabilities.

Needle valves

Needle valves are precision valves used in applications that require precise flow control. They have an extended, tapered, needle-shaped disk that can be adjusted to regulate the fluid flow by increasing or decreasing the opening size. It makes them ideal for fine-tuning and throttling control.

One critical benefit of needle valves is their exceptional capability to withstand and control high pressures and temperatures, rendering them highly suitable for critical operations. Analytical and instrumentation systems and industries such as oil and gas, petrochemicals, and pharmaceuticals commonly use needle valves.

Needle valves also come in various designs, including rising stem, non-rising stem, and multi-turn. In a rising stem design, the handwheel and spindle move up and down as the valve opens or closes. In contrast, in a non-rising stem design, the handwheel stays in place while the spindle moves up or down to open or close the valve.
